10 ✖ 10 mm Top Bending Silicone Neon LED Strip
A 1270 Meter US Order for Outdoor Use
A US customer placed an order with Xmartlights for 1,270 meters of 10×10mm top bending silicone neon LED strip, specified for outdoor installation. Water protection was a key requirement, alongside 3000K warm white light and a compact profile.
The selected configuration combines IP65 protection, DC24V input, 10W/m, SMD2835 LEDs, and CRI 90+. Supplied in 10-meter rolls, the order totals 127 rolls. Below, we look at the specifications, product details, and installation considerations that matter when sourcing this strip for an outdoor project.
Illuminated product sample showing the warm white appearance. This is a bench demonstration, not a completed outdoor installation.
Product Model and Order Specifications
The packaging identifies the product as “1010top bending neon strip”. The specifications below combine the information on the photographed label with the confirmed order details.
Specification | Configuration for this order |
Product | 10×10mm Top Bending Silicone Neon LED Strip |
Model / PN on label | 1010top bending neon strip |
Profile dimensions | 10mm × 10mm |
Bending type | Top bending |
Housing | Silicone |
LED type | SMD2835 |
Input voltage | DC24V |
Power consumption | 10W/m |
Color temperature | 3000K warm white |
Color rendering index | CRI 90+ |
Beam angle | 120° |
Ingress protection | IP65 |
Ambient temperature (Ta), per label | −20°C to +35°C |
Roll length | 10 meters |
Order quantity | 1,270 meters / 127 rolls |
Destination and intended use | United States / outdoor installation |
The product label provides the electrical, optical, and environmental specifications for this configuration.
Key Advantages for Lighting Projects
A compact 10×10mm profile
The slim silicone housing is useful where the lighting needs to fit into a narrow architectural detail. When planning the installation, allow additional space for mounting accessories, end caps, and cable routing.
Close-up of the silicone housing and cable-end construction.
3000K warm white with CRI 90+
Warm white light can create a welcoming atmosphere around outdoor seating areas, hospitality spaces, and architectural accents. The labeled CRI 90+ specification supports natural-looking color rendering—useful where the appearance of surrounding finishes and materials matters.
The illuminated photos show a continuous-looking line of light through the diffuser. Evaluate a sample in the intended setting to confirm the appearance; camera exposure and screen settings can affect how brightness and color look in photographs.
A close-up of the illuminated diffuser and cable end during a bench demonstration.
Top bending for compatible curved routes
This model bends in a specified plane. The attached direction tag provides a visual reference when checking whether the product suits the proposed lighting route. Match that direction to the design and confirm the minimum bending radius before installation.
DC24V identification, bending-direction guidance, and power leads on the photographed product.
10-meter rolls for straightforward quantity planning
For this US order, 127 rolls provide a total of 1,270 meters. Consistent roll lengths make it easier to count stock and allocate material across installation areas. The supplied roll length does not establish the maximum electrical run; confirm the power-feed arrangement separately.
IP65 Protection Details That Matter Outdoors
IP65 means dust-tight protection and resistance to water jets. It does not indicate suitability for immersion. For outdoor projects, assess both the exposure conditions and the protection of the complete installed system. Reference: Halco Lighting’s explanation of IP ratings.
The following close-ups show the cable entry and end cap. These areas deserve attention during installation because connections, cut ends, and cable entries must retain appropriate protection.
Cable-entry detail on the supplied product.
End-cap and cable-exit detail from another angle.
Use the specified sealing method for any permitted cuts or connections, and select suitable protection for power supplies and junctions. Avoid positions where water can collect around the strip. The exposed leads and test clips in the illuminated photos show a temporary demonstration setup; final outdoor connections require appropriate enclosures or sealing.
Also check the labeled ambient temperature range of −20°C to +35°C against the actual location, including sun-exposed mounting surfaces. Discuss more demanding temperature or water-exposure conditions before ordering.
Power Planning for a 24V, 10W/m Neon Strip
At 10W/m, each 10-meter roll represents a nominal strip load of 100W. Use this as a starting point when planning the electrical layout, then confirm power-supply capacity allowance, cable sizing, maximum run length, and feed locations.
A 10-meter roll should not automatically be treated as a single-end-powered run. The correct arrangement depends on the product requirements and installation layout.
Frequently Asked Questions
Can this IP65 neon strip be used outdoors
This order was specified for outdoor use. Suitability for a particular site depends on water exposure, temperature, mounting, and connection protection. It should not be used as an underwater light.
Can the strip bend in any direction
No. Follow the top-bending direction shown on the product tag, avoid twisting, and confirm the permitted bend radius for your design.
What should I include in a quotation request
Send the required quantity, color temperature, installation drawings or photos, outdoor exposure conditions, delivery destination, and target schedule. Include any certification requirements so the proposed configuration can be checked against your project needs.
